Grundfos CME 3-3-I A R I E AQQE Horizontal Multi-Stage Booster Pump 415V

Part Number:
98395157
This item is now obsolete. Please view our alternatives below.
£2,414.40 RRP £1,690.08 £1,408.40

Free Delivery Over £50

Grundfos CME 304 Stainless Steel Horizontal Multi-Stage Booster Pumps with new MGE/MLE motors represent the state-of-the-art speed-controlled motors and efficiency.  Total efficiency of the new motor, including the frequency converter makes the CME unique for its class when it... Read More
1 year warranty With This Product

CME 3-3 A-R-I-E-AQQE S-A-D-N

Compact, reliable, horizontal, multistage, end-suction centrifugal pump with axial suction port and radial discharge port. Pump materials in contact with the liquid are in stainless steel. The mechanical shaft seal is a special designed, unbalanced O-ring seal. Pipework connection is via internal Whitworth pipe threads, Rp (ISO 7/1). The pump is fitted with a 3-phase, fan-cooled, permanent-magnet, synchronous motor. The motor efficiency is classified as IE5 in accordance with IEC 60034-30-2. The motor includes a frequency converter and PI controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement. An operating panel on the motor terminal box enables setting of required setpoint as well as setting of pump to "Min." or "Max." operation or to "Stop". The Grundfos Eye indicator on the operating panel provides visual indication of pump status:

  • "Power on": Motor is running (rotating green indicator lights) or not running (permanently green indicator lights)
  • "Warning": Motor is still running (rotating yellow indicator lights) or has stopped (permanently yellow indicator lights)
  • "Alarm": Motor has stopped (flashing red indicator lights).

Communication with the pump is possible by means of Grundfos GO Remote (accessory). The remote control enables further settings as well as reading out of a number of parameters such as "Actual value", "Speed", "Power input" and total "Power consumption". The terminal box holds terminals for these connections:

  • one dedicated digital input
  • two analog inputs, 0(4)-20 mA, 0-5 V, 0-10 V, 0.5 - 3.5 V
  • 5 V voltage supply to potentiometer and sensor
  • one configurable digital input or open-collector output
  • Grundfos Digital Sensor input and output
  • 24 V voltage supply for sensors
  • two signal-relay outputs (potential-free contacts)
  • GENIbus connection
  • interface for Grundfos CIM fieldbus module.
More Information
Price £1,408.40
Manufacturer Grundfos
Warranty 1 year warranty
Dimensions 233mm (h) x 268mm (w) x 365.9mm (d)
Impeller Type Horizontal multistage
Electrical supply 415V
AC Power Three Phase
Speed Variable
Flow Rate 86 Ltr/min
Max Head 40m
Water type Clean or Discoloured
Pump Type Booster Set
Duty Type Commercial
Submersible vs Surface Mounted Surface Mounted
Next Day Delivery No
Manufacturers Part Number 98395157
