Grundfos CME 3-6-I A R I E AQQE Horizontal Multi-Stage Booster Pump - 240v
This item is now obsolete. Please view our alternatives below.
Free Delivery Over £50
1 year warranty With This Product
CME 3-6 A-R-I-E-AQQE U-A-D-N
Compact, reliable, horizontal, multistage, end-suction centrifugal pump with axial suction port and radial discharge port. Pump materials in contact with the liquid are in stainless steel. The mechanical shaft seal is a special designed, unbalanced O-ring seal. Pipework connection is via internal Whitworth pipe threads, Rp (ISO 7/1). The pump is fitted with a 1-phase, fan-cooled, permanent-magnet, synchronous motor. The motor includes a frequency converter and PI controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement.
| Controls: | ||
| Frequency converter: | Built-in | |
| Liquid: | ||
| Pumped liquid: | Water | |
| Liquid temperature range: | -4 .. 248 °F | |
| Selected liquid temperature: | 68 °F | |
| Density: | 62.29 lb/ft³ | |
| Technical: | ||
| Rated pump speed: | 3480 rpm | |
| Rated flow: | 16.4 US gpm | |
| Rated head: | 196.2 ft | |
| Code for shaft seal: | AQQE | |
| Approvals: | CE,WRAS,ACS,TR,EAC,CURUS | |
| Curve tolerance: | ISO9906:2012 3B | |
| Materials: | ||
| Pump housing: | Stainless steel | |
| EN 1.4301 | ||
| AISI 304 | ||
| Impeller: | Stainless steel | |
| EN 1.4301 |
| Price | £1,516.90 |
|---|---|
| Manufacturer | Grundfos |
| Warranty | 1 year warranty |
| Dimensions | 248mm (h) x 212mm (w) x 403.8mm (d) |
| Impeller Type | Horizontal multistage |
| Electrical supply | 240V |
| AC Power | Single Phase |
| Speed | Variable |
| Flow Rate | 86 Ltr/min |
| Water type | Clean or Discoloured |
| Pump Type | Booster Set |
| Switch | None |
| Duty Type | Domestic |
| Next Day Delivery | No |
| Connection Size | 1 inch |
| Manufacturers Part Number | 98395306 |
