Grundfos UPS 32-100N Hot Water Service Circulator - 240v


Click on image to zoom

More Images

Grundfos UPS 32-100N Hot Water Service Circulator - 240v
Hot Water Service Circulator pump is suitable for domestic hot water applications up to 110°C.
Part Number: GR-98057249

Share this product

Downloads & Manuals

Download Datasheet PDF

£843.00 RRP

£548.00 [Ex. VAT]
Including VAT £657.60
*on orders over £50
1 year guarantee
EUP Ready

Product Details

UPS 32-100 N 180
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricatd by the pumped liquid. The pump has 3-step speed selector. The pump is characterized by:

  • Stainless steel shaft.
  • Ceramic radial bearing system.
  • Carbon axial bearing.
  • Stainless steel rotor can and bearing plate.
  • Corrosion-resistant impeller, Composite, PES/PP.
  • Stainless steel pump housing.

The motor is a 1-phase motor. No additional motor protection is required.

Pumped liquid:    Water
Liquid temperature range:    -25 .. 110 °C
Selected liquid temperature:    60 °C
Density:    983.2 kg/m³
TF class:    110
Approvals on nameplate:    CE,WEEE
Pump housing:    Stainless steel
     DIN W.-Nr. 1.4301
Impeller:    Composite, PES/PP
Delivery & Returns

Pump Sales Direct (PSD) offers a free standard delivery service (2-3 working days) to mainland UK*. The free standard delivery service relates to all pumps on our website and also individually purchased spares or accessories over the value of £50 (before VAT). Individual spares or accessories purchased under £50 will incur a £6.95 delivery charge.

PSD also offers a next day delivery service at a charge of £7.50*, provided we receive your order before 3:30pm Monday to Friday (excludes Weekends and Bank Holidays).

*Excludes UK Islands, Republic of Ireland, Northern Ireland and Scottish Highlands.

UK Delivery Charge Options:-

Standard Delivery (2-3 working days)* - FREE

Next Working Day Delivery (on orders placed before 3:30pm)* - £7.50

Next Working Day Delivery before 10.30 am (on orders placed before 3:30pm)* - £25.00

Next Working Day Delivery before 12.00pm (on orders placed before 3:30pm)* - £15.00

Saturday AM Delivery before 12.00pm*- £35.00

Scottish Highlands Standard Delivery - £17.50

UK Islands & Republic of Ireland Standard Delivery - £25.50

*Excludes UK Islands, Republic of Ireland, Northern Ireland and Scottish Highlands.

Additional Information

Additional Information

Manufacturer Grundfos
Guarantee message 1 year guarantee
Dimensions 180mm (h) x 158mm (w) x 197mm (d)
Bars No
Impeller type No
Electrical supply 240V
AC Power Single Phase
Speed No
Cable length No
Flow rate 216 Ltr/min
Max Head No
Pump Operation No
