Wilo Economy MHIE 406N-2G EPDM 1.4301 Centrifugal Pump

Zoom

Click on image to zoom

More Images

Wilo Economy MHIE 406N-2G EPDM 1.4301 Centrifugal Pump
2.2kW three phase multistage centrifugal pump, with 1" threaded connections
Part Number: WIL-4148418

Share this product

£3,175.20 RRP

£1,985.00 [Ex. VAT]
Including VAT £2,382.00
OR
FREE DELIVERY
*on orders over £50
1 year guarantee
EUP Ready
Description

Product Details

Buy the Wilo Economy MHIIE 406N-2G EPDM 1.4301 Centrifugal Pump from Pump Sales Direct and recieve free standard delivery.

Need techinical advice on the product? Give our technical team a call on: 0800 008 6405

Multistage, non-self-priming, horizontal high-pressure centrifugal pump in block design with horizontal suction port and vertical pressure port and built-in, air-cooled frequency converter. The integrated frequency converter enables variable speed, pressure and PID control.

Speed control

  • "Speed control" : Manually with green button or via external signals
  • "Differential pressure, constant" : Pressure control with pressure sensor, setpoint adjustment via green button or via external signals
  • "PID control": other constant control variables (temperature, volume flow, pressure....) with sensor, setpoint adjustment with green button, by means of external signals

The electronic module provides various protective functions. They include overload protection, the detection of low water, mains undervoltage or overvoltage, high ambient temperature, missing phases, blocked pumps and short-circuits. Error messages are issued on the display.

Short-circuit-proof +24 V voltage output with max. contact strength of 30 mA is present on the electronic module. The module has potential-free contacts for SSM, red and green LED for ON/OFF signal.

Delivery & Returns

Pump Sales Direct (PSD) offers a free standard delivery service (2-3 working days) to mainland UK*. The free standard delivery service relates to all pumps on our website and also individually purchased spares or accessories over the value of £50 (before VAT). Individual spares or accessories purchased under £50 will incur a £6.95 delivery charge.

PSD also offers a next day delivery service at a charge of £7.50*, provided we receive your order before 3:30pm Monday to Friday (excludes Weekends and Bank Holidays).

*Excludes UK Islands, Republic of Ireland, Northern Ireland and Scottish Highlands.

UK Delivery Charge Options:-

Standard Delivery (2-3 working days)* - FREE

Next Working Day Delivery (on orders placed before 3:30pm)* - £7.50

Next Working Day Delivery before 10.30 am (on orders placed before 3:30pm)* - £25.00

Next Working Day Delivery before 12.00pm (on orders placed before 3:30pm)* - £15.00

Saturday AM Delivery before 12.00pm*- £35.00

Scottish Highlands Standard Delivery - £17.50

UK Islands & Republic of Ireland Standard Delivery - £25.50

*Excludes UK Islands, Republic of Ireland, Northern Ireland and Scottish Highlands.

Additional Information

Additional Information

Manufacturer Wilo
Guarantee message 1 year guarantee
Dimensions No
Bars No
Impeller type No
Electrical supply 400V
AC Power Three Phase
Speed No
Cable length No
Flow rate No
Max Head No
Pump Operation No
